Boland LVB17 LED Broadcast Monitor 17 Zoll

Beschreibung

Boland LVB17 LED Broadcast Monitor 17 Zoll (LVB 17)
Boland Communications, gegründet im Jahr 1979, mit Hauptsitz in Lake Forest, Kalifornien, USA bietet Premium LCD und LED Monitore in allen gängigen Formaten. Boland Broadcast Monitore stehen für erstaunliche Bilder mit verbesserter Ultra-Pixel Bildqualität bei wechselnden Licht- und Sichtverhältnissen.
Boland LVB17 LED Broadcast Monitor 17 Zoll Features
17.3” HD & SD SDI Digital, Analog, HD HDMI/DVI (+HDCP)
High & Standard Definition Video LCD Monitors 1080/720/576/480(@60/59.94/50)
3G includes 2x3G HD/SD SDI-Digital input/ HD HDMI/DVI (+HDCP)
HDMI/DVI inputs accepts up to 1080p HD
Modes: EGA to UXGA, NTSC/PAL/SECAM/NTSC4.43/PAL-M
Analog Inputs are Composite, Y/C, Component, RGB (SOG), DVI – I (Analog PC)
Aspect Ratio: 16:9, 4:3, 14:9, 13:9, 1.85:1, 2.35:1:
Marker Display. •UMD Support.
Color Temperature – User, VAR, 11000K, 9300K, 6500K, 5400K, 3200K
Specifications
Active Area (Diagonal): 17.3”
Modes
High & Standard Definition Video Modes: 1920x1080p(50/60/30psf/25psf/24psf/30/25/24),1920x1080i(50/60), 1280x720p(50/59.94/60), 480i(59.94),576i(50)
Digital, VESA VGA, DVI/HDMI
*24psf/23.98psf signal format is not supported in “UNDERSCAN ” Mode.
PC Video Modes: EGA, VGA, SVGA, XGA, WXGA, SXGA, WSXGA, UXGA
Standard Definition Video Modes: NTSC/PAL/SECAM/NTSC4.43/PAL-M
Scanning Modes: Under/Over/Zero/Pixel to Pixel Scanning
Inputs
Digital Video Inputs: 3G HD SDI (@50/59.94/60), HD HDMI/DVI (+HDCP)
Digital Video Inputs: Digital Visual Interface, VESA & SMPTE Rates.
Analog Video Inputs: Composite, Y/C, Component, RGB (SOG), DVI – I (Analog PC)
Aspect Ratios: Full Screen, 16:9, 4:3, 14:9, 13:9, 1.85:1, 2.35:1
Picture-in-Picture : Analog (Composite1, 2, 3, YPbPr, GBR, PC), SDI 1 inputs + SDI 2, Digital (DVI, HDMI) input PIP
Picture-by-Picture: Side by Side split screen display
Pixel (RGB Trio) Arrangement: 1920 H 1080 V Pixels RGB strip arrangement (2,073,600 Pixels, 16:9)
Pixel (RGB Trio) Pitch, Depth: 0.1989 X 0.1989 mm
Brightness, typical, 0°: 300 cd/m2
Contrast Ratio, 0° 500:1
Color Processor: 10 bit color Processor
Viewing Angle, contrast>10:1 : Horizontal: 120(Typ), Vertical 100(Typ), 500:1
Response Time: 8 ms
Controls
User Controls: STANDBY, SDI 1, SID 2, ANALOG, MARKER, FUNCTION, MENU, UP, DOWN, SEL/INPUT
Remote Controls: IR, TCP/IP, RS-422, RS-232
Backlight
Light Source (standard): LED backlight system
LED Life: 12,000 Hrs
CONNECTORS
Video Connectors: BNC 2 SDI 2 Channel Input, BNC 3 Composite, YC (S-Video), Component (YPbPr/RGB) Input
HDMI/DVI Connectors: DVI-I 1 DVI & Analog RGB Input, HDMI 1 HDMI Input
Power
DC Power: 12 VDC ±10%, 30 watts
DC Connector: XLR-4M (pin 1=Gnd, pin 4=+volts)
AC Power (detached power supply included): 90-264 VAC, 50/60 Hz
AC Power Connector: IEC 320-C14 3 pin Male
Display
Window (Display Area): 15.03 9.52”/381.888 mm 214.812 mm
Cabinet Dimensions: -15.8×10.2×2.2” / 403 260 58mm (whd)
Weight: 16.5 lbs / 7.5kg
Mounting / Rack Mounting: VESA (100 100), Rackmount 6 RU
Operating (full spec): 0 ~ +50°C, no condensation, 0 ~ 10,000 feet (3,048m)
Storage: -20 ~ +60°C, no condensation, 0 ~ 40,000 feet (12,192m)
Available Options: –

Weitere technische Daten entnehmen Sie bitte dem Datenblatt im Downloadbereich
